20
Installation
Preparation of the work surface
• Cut out the work surface according to the sizes shown in the drawing.
• For the purpose of installation and use, a minimum of 50mm space shall b
e
preserved around the hole.
• Be sure the thickness of the work surface is at least 30mm. and suitable for the
application.
L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm)
HNTB64CE 590 520 50 46 560 490 50 min
E
nsure the hob is well ventilated and the air inlet and outlet are not blocked. Ensure
the hob is in good working order.
Install Rangehoods and Exhaust Fans in accordance to the manufacturer’s
instructions. No closer than 600mm above the hob for Rangehoods and 750mm for
Exhaust Fans.
