VREF
10
6
I Internal voltage reference to video DAC.
YUV1 O YUV pixel 1 output data.
PIXOUT1 O CCIR656 output pixel 1.
COM
P
10
7
I Compensation input
.
YUV3 O YUV pixel 3 output data
.
PIXOUT3 O CCIR656 output pixel 3.
RSET
10
8
I DAC current adjustment resistor input.
YUV4 O YUV pixel 4 output data.
PIXOUT4 O CCIR656 output pixel 4.
FDAC
10
9
O Video DAC output. Refer to description and matrix for UDAC pin 115.
YUV7 O YUV pixel 7 output data.
PIXOUT7 O CCIR656 output pixel 7.
VDAC
110
O Video DAC output. Refer to description and matrix for UDAC pin 115.
YUV6 O YUV pixel 6 output data.
PIXOUT6 O CCIR656 output pixel 6.
VD33_DA 111 P Power for I/O power supply for VDAC
.
VS33_DA 112 G Ground for I/O power supply for VDAC.
YDAC
113
O Video DAC output. Refer to description and matrix for UDAC pin 115.
YUV5 O YUV pixel 5 output data.
PIXOUT5 O CCIR656 output pixel 5.
CDAC
11
4
O Video DAC output. Refer to description and matrix for UDAC pin 115.
YUV2 O YUV pixel 2 output data.
PIXOUT2 O CCIR656 output pixel 2.
ES6688A Pi
n Description (Continued)
Names Pin Numbers I/
O Definitions
