Bematech I-150 User Manual

Barcode Scanner Configuration Procedure
1. System Information
Set All Default (+RETF)
Read Version (+SFVR)
② Scan the necessary configuration barcodes to
match application requirements
System Settings
Select Terminator
Reading Mode Selection
Symbologies Selection
③ Scan the “End Configuration” barcode below
① Scan the “Start Configuration” barcode below

Bematech I-150 Specifications

General

Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D
Read rate (max)	280 reads/s
Yaw reading angle	-25 - 25 °
Tilt reading angle	-55 - 55 °
Pitch reading angle	-75 - 75 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, MSI, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Not supported
Cable length	1.4 m
Standard interfaces	USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	20 - 50 °C
Operating relative humidity (H-H)	5 - 98 %
Certification	EMC CE & FCC DOC, VCCI IEC 62471
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP52
Input voltage	5 V
Power consumption	140 mA

Weight and Dimensions

Depth	121.6 mm
Width	66.3 mm
Height	162.8 mm
Weight	200 g
