ASSEMBLY INSTRUCTIONS
5 GAL(19L) AIR COMPRESSOR
1635-709
· Unpack the air compressor unit. Inspect the unit for damage. If the unit has been damaged, contact
the retailer immediately.
·
Check the air compressor’s identification label to ensure that you have purchased the intended
model and that it has the required pressure rating for its intended use.
1. Position the air compressor (1) near an electrical outlet (2)(FIG. A).
2. The compressor must be at least 12”(31cm) from any wall (3) or abstruction, in a clean,
well-ventilated area to ensure sufficient air flow and cooling(FIG. A).
3. Place the air compressor on the floor or a hard, level surface.
4. Connect the air hose (1) to the compressor’s air outlet (universal coupler) (2) with the universal quick
plug (3) (FIG. B).
Attach air hose and accessories (not provided). Apply plumber’s tape on all the threads to prevent air
leakage.
NOTE
Product Features
Positioning of the air compressor
DESCRIPTION
Air compressor
Owner’s manual
1
1
QTY ILLUSTRATION
FIG. A FIG. B
1
1
2
3
2
3
