PARTS LIST
5 GAL(19L) AIR COMPRESSOR
1635-709
Key#
1 1Control Panel
Part name Quantity
18
2 1Pressure Regulator Knob
3 1Screw M4x10
4 9Bolt M5x12
5 1Cam Lock (II)
6 1Handgrip
7 1Handle
8 2Nut
9 2Bolt M6x34
10 2Spring
11 1Cam Lock (I)
12 2Lock Nut
13 2Plastic Washer
14 2Lever
15 1Rubber Hose
16 1Motor Pump Assembly
17 1Air Filter
18 6Screw ST3.9x16F
19 1Right Shroud
20 3Screw 8# X 9
21 2Pin
22 2Wheel
23 1Rear Motor Retaining Plate
24 1Line Card
25 1Before Motor Retaining Plate
26 2Steel Pipe Sheath
27 1Bleeding Tube
28 1Clamp
29 1Switch Box
30 6Screw M5x14
31 1Power Cord
32 1Power Switch
33 3Cushion Pad
34 1Retainer
35 3Screw 1/4-20x19
36 1Left Shroud
37 3Screw 10#x15
38 1Rubber Hose
39 2Clamps
40 1Pressure Regulator
41 2Quick Coupler
42 2Pressure Gauge
43 1Safety Valve
44 2Elbow Fitting
45 1Pressure Switch
46 1Check Valve
47 1Ball Valve
48 2Sliding Sleeve
49 1Tank
50 2Screw M8x8
51 2Rubber Foot
52 2Bolt M6x16
