PREPARATION BEFORE OPERATION
HOW TO SET UP YOUR UNIT
1. Push and press the telescopic handle release button, then pull upward the
telescopic handle for moving the machine easily.
2. Push out the hose reel crank from the left to the right for easily rewinding and
winding the hose to proper use or storage.
3. Install gun holder and power cable hook, vertically screwing the gun saddle tight
to the main body as seen in the illustration. The screws will be packed together with
the main body, check for them when you unpack the unit.
PUSH
4. Insert the lance into the gun. Push and turn the adjustable nozzle clockwise onto
the gun until hand tight to lock it in place. When the piecesare joined properly,
you cannot separate the two components by pulling straight out on the lance. All
attachments must be inserted into the gun for proper use.
5. Attach spray gun to high pressure hose.
