Tal
4 1/2”
(11 CM)
5”(12.5 cm)
19
FIG. 14
FIG. 16
FIG. 18
FIG. 15
FIG. 17
FIG. 19
9. Align the notches of the spool from which the lines protrude with the eyelets in the
spool retainer and position the spool in the retainer (FIG 17).
10. Holding the spool and spool retainer, grasp one end of the line and pull it to
release the line from the notch in the eyelet (FIG 18). Repeat with the other end.
11. With the spool base facing downward, align the slots in the spool retainer with
the tabs on the spool base and press the retainer evenly down until it snaps into
place (FIG. 20).
