MOUNTING THE MULCHING KIT
If you decide to mow, mulch, and leave the grass on the lawn, assemble the
mulching kit on the cutting deck as indicated below.
1. Open the side deflector up.
2. Pass the pivot boss (M) on the
mulching kit under and through the
bottom of the side deflector’s pivot
pin (N) (Figure 1).
3. Insert the right dowel pin into the hole
of deck (Figure 2, Details C & D).
4. Insert the left dowel pin (Part E) into
the self-locking base (Figure 3, Detail
E).
5. Put down the side deflector (Figure 3).
