32
PARKING BRAKE LEVER (14)
With machine stopped:
▪ Keep the brake pedal pressed.
▪ Lift the parking brake lever and keep
lifted.
Release the pedal:
▪ This way, the rear wheels remain
braked. To release the parking
brake, fully press the brake pedal
(the parking brake lever is
automatically released and returns
to down position).
The engine can only be started in the parking position, while sitting on the
machine and with either the parking brake lifted, or brake pedal pressed.
DRIVE ENGAGEMENT (15) (for hydrostatic transmission)
This pedal engages drive in the wheels
as well as modulating the machine’s
forward and reverse speeds.
1. To engage forward drive, press it
towards F with your toecap. As you
increase the pressure on the pedal,
the speed of the machine increases.
2. The reverse is engaged by pressing
the pedal with the heel towards R.
3. The pedal automatically goes into
neutral N when released.
The reverse must only be engaged when the machine is stopped.
Make sure the parking brake has been released before driving the mower.
