For a flat lawn, if required, you can change the position of the deck wheels to obtain
a lower cut.
For a heavy lawn, it is recommended to set the wheel in the hole at A.
In case of any doubts, do not hesitate to contact your retailer.
REPLACING WHEELS
1. Stop the machine on flat ground
and put a block under a load-
bearing part of the frame on the
side that the wheel is to be
changed.
2. The wheels are held by a snap ring
which can be eased off with a
screwdriver.
If you must replace one or both rear wheels, they must have the same diameter,
and check that the cutting Deck (4) is horizontal to prevent an uneven cut. You must
make sure the key and washer are securely lodged in place.
Before remounting the wheel, apply grease to the axle. Put the snap
ring and supporting washer back in place.
