6 720 611 451 GB (03.11)
10
Details of the appliance
Condensate analysis, mg/l
Flue system
Elbow - 90 ° Equivalent length 2 m
Bend - 45 ° Equivalent length 1m
Gas supply
Domestic water performance
Ammonium 1.2 Nickel 0.15
Lead ≤ 0.01 Mercury ≤ 0.0001
Cadmium ≤ 0.001 Sulphate 1
Chromium ≤ 0.005 Zinc ≤ 0.015
Halogenated
hydrocarbons ≤ 0.002
Tin ≤ 0.01
Hydrocarbons 0.015 Vanadium ≤ 0.001
Copper 0.028 pH-value 4.8
Table 3
HORIZONTAL 100 mm – Standard FLUE SYSTEM
Overall Diameter of Duct mm 100
Max.
4m
Flue Terminal / Duct
Assembly Length
mm 600
Extension Duct Length mm 1000
Table 4
HORIZONTAL 125 mm FLUE SYSTEM
Overall Diameter of
Duct
mm 125 Max. 13 m
(including
turret)
Flue Terminal / Duct
Assembly
mm 1030
Table 5
VERTICAL 100 mm FLUE SYSTEM
Overall Diameter of Duct mm 100
Max.
13.7m
(Excl.
Terminal)
Flue Terminal / Duct
Assembly
mm 1140
Table 6
VERTICAL 125 mm FLUE SYSTEM
Overall Diameter of Duct mm 125
Max. 5m
(Excl.
Terminal)
Flue Terminal / Duct
Assembly
mm 1365
Table 7
Total length of gas supply pipe
(metres)
Pipe diameter
(mm)
369
Gas discharge rate (m
3
/h)
8.7 5.8 4.6 22
18.0 12.0 9.4 28
Table 8
Domestic
Water Flow
Rate l/min
Temperature
Rise 30 °C 15.6
Temperature
Rise 35 °C 13.3
Temperature
Rise 40 °C 11.7
Maximum Mains pressure bar 10.0
Minimum Mains pressure bar 0.2
Table 9
