24 Bend-Tech Dragon A150
Plasma Cutting Guide
Cutting Charts
02
85 Amp: Mild Steel
Material
Thickness
Cutting
Height
Pierce
Height
Dwell
Time
Cutting
Feed Rate
Cutting
(in.) (in.) (in.) (sec) (ipm) AMPs
0.0625 0.06 0.09 0
60 30-35
80 35-40
100 40-45
120 45-50
140 50-55
0.125 0.07 0.1 0
60 40-45
80 45-50
100 50-55
120 55-60
140 60-65
0.1875 0.08 0.11 0
60 45-50
80 50-55
100 55-60
120 60-65
140 65-70
0.25 0.09 0.12 0.25
60 65-70
80 70-75
100 75-80
120 80-85
0.375 0.08 0.12 0.5
60 70-80
80 80-85
