30 Bend-Tech Dragon A150
Plasma Cutting Guide
Plasma System Gas Supply
04
maintain 100 psi at the end of the 100 ft. run the compressor would be required to have a 134
For high-volume cutting it is recommended that the user have a compressor that is 1.5-2 times
the minimum system requirements. Optimum air supply setup for the Dragon A150 using a
Hypertherm unit is a compressor that can maintain 180 psi and 12 cfm.
cutting operations. Filter systems that meet these requirements are readily available online and
from many commercial outlets.
Proper gas delivery is critical to maximizing the life of
consumables:
• Ensure there are no leaks or restrictions
•
•
dryer and oil separator
• Ensure gas pressure is set correctly
Compressor
6 cfm / 90psi x 1.5-2
Air Filter
Air Dryer
Oil Separator
Moisture Traps
Recommended:
Minimum 1 in. Pipe
Air supply should not
drop below minimum
requirement before
regulator: 6cfm / 90psi.
Gauge and Regulator
Plasma Unit
To Next Page
