Active or Inactive Diagnostic Trouble Codes:
INDEX
How to interpret the first digit of messages received when
Active or Inactive Diagnostic Trouble Code Mode is entered.
1st
Blink
Code
Number
1 ............................................... No faults (1,1)
2 ............... Wheel Speed Sensors - page 18
3 ............... Wheel Speed Sensors - page 18
4 ............... Wheel Speed Sensors - page 18
5 ............... Wheel Speed Sensors - page 18
6 .............................. Power Supply - page 23
7 ........ Pressure Modulator Valves - page 20
8 ........ Pressure Modulator Valves - page 20
9 ........ Pressure Modulator Valves - page 20
10 ....... Pressure Modulator Valves - page 20
11 .......................................... J1939 - page 24
12 ............................ Miscellaneous - page 26
13 .............................................ECU - page 25
14 .............. Wheel Speed Sensors - page 18
15 .............. Wheel Speed Sensors - page 18
16 ....... Pressure Modulator Valves - page 20
17 ....... Pressure Modulator Valves - page 20
18 ................ Traction Control Valve - page 22
Example: For a message sequence of:
3, 2 12, 4
For the first sequence go to page 18 and
for the second sequence go to page 26.
Go Here for Troubleshooting Tests
See Page 42 for Appendix A: J1587 SID and FMI Codes and Their Bendix Blink Code Equivalents

BENDIX EC-60 ABS-ATC STD-PREM CONTROLLERS Specifications

General

Function	Anti-lock Braking System (ABS) and Automatic Traction Control (ATC)
Operating Temperature	-40°C to +85°C
Type	ABS-ATC Controller
Variants	Standard, Premium
Inputs	Wheel speed sensors
Supply Voltage	12V / 24V DC
