BENDIX Wingman Fusion User Manual

11
System Overview
Integrating camera, radar, and brakes, the Bendix
®
Wingman
®
Fusion
™
Active
Safety System provides the following alerts and actions:
1. Stationary Vehicle Braking (SVB);
2. Enhanced Collision Mitigation Braking (CMB);
3. Active Cruise with Braking (ACB);
4. Overspeed Alert and Action (OAA);
5. Lane Departure Warnings (LDW);
6. Stationary Object Alerts (SOA); and
7. Alert prioritization.
See the diagram below
NOT TO SCALE
Detected Forward
Vehicle
The STRIPED area approximates
the zone where the Active Cruise
with Braking feature is ready to
alert – and intervene with the
vehicle’s brakes – when the cruise
control is set.
The DARK GREY area approximates
the zone where the Wingman
Fusion system is ready to alert – and
intervene with the vehicle’s
brakes – as long as the vehicle is
traveling above 15 mph / 24 kph.
What Features are Included in the
Bendix Wingman Fusion System?
Part One: Active Cruise with Braking
Think of the Active Cruise with Braking (ACB) feature as an additional upgrade
to ordinary cruise control. When using cruise control, your vehicle not only
will maintain the set speed, but the system will also intervene – as needed – to
help maintain a set following distance behind the vehicle in front of you.
Using a radar (with a range of approximately 500 feet) mounted to the front
of your vehicle, the System reacts ONLY to vehicles moving in the same
direction as you. (The system DOES NOT respond to side‑to‑side moving
traffic or oncoming traffic.)
See the STRIPED area in the diagram above. The Active Cruise with Braking
feature is designed to help maintain a set following distance between your
vehicle and the vehicle ahead when cruise control is set.

BENDIX Wingman Fusion Specifications

General

Radar	Yes
Camera	Yes
Features	Collision Mitigation, Adaptive Cruise Control, Lane Departure Warning
Braking	Automatic Emergency Braking
Integration	Integrated
Power Supply	24V
