13
SECTION 6
(COMMUNICATION CABLE
CONNECTION AND POSITIONING
PROCEDURE)
1. Position each column as shown below. Column A
“Master Column” should be located closest to the power
supply. (See Fig 6.1)
2. Route and connect the Communication Cables
according to the pictures and diagrams below. Pull back
on Locking Tab to lock Communication Cable to the
Column connectors. (See Fig. 6.2 - 6.4)
Fig. 6.2 Fig. 6.3
Fig. 6.4
Fig. 6.1
MAIN POWER SWITCH MUST BE OFF BEFORE
CONNECTING OR DISCONNECTING ANY OF
THE COMMUNICATION CABLES. FAILURE TO
FOLLOW PROPER PROCEDURE CAN RESULT IN
DAMAGE TO THE ENTIRE CONTROL SYSTEM.
