Crossbeam Accessory
The PCL-18B has a Crossbeam available as an accessory.
The Crossbeam goes between two PCL-18Bs, sitting in their troughs.
The Crossbeam comes with adapters: two cradle adapters (which fit onto the Crossbeam), two short
cradle lift adapters, and two tall cradle lift adapters.
The Crossbeam also comes with a caster kit, which allows the Crossbeam to be easily moved around.
Caster
Cradle
Adapter
Tall Cradle
Li Adapter
Short Cradle
Li Adapter
The Crossbeam can support a full 36,000 lbs / 8165 kg for much of its length of 122 inches / 3098.8
mm. However, as the adapters are moved towards the middle of the Crossbeam, the load that can be
supported is reduced to a maximum total of 12,950 lbs.
122 inches /
3098.8 mm
43.875 in /
1114.425 mm
43.875 in /
1114.425 mm
34.25 in /
870 mm
18,000 lbs /
8165 kg
18,000 lbs /
8165 kg
12,950 lbs /
5874 kg
