12
SECTION 5
(ELECTRICAL CONNECTIONS)
• ALL WIRING MUST BE PERFORMED BY A LICENSED ELECTRICIAN.
• DO NOT PERFORM ANY MAINTENANCE OR INSTALLATION OF ANY
COMPONENTS WITHOUT FIRST ENSURING THAT ELECTRICAL POWER
HAS BEEN DISCONNECTED AT THE SOURCE OR PANEL AND CANNOT
BE RE-ENERGIZED UNTIL ALL MAINTENANCE AND/OR
INSTALLATION PROCEDURES ARE COMPLETED.
• DO NOT RUN POWER UNIT WITHOUT OIL. DAMAGE TO POWER UNIT
PUMP CAN OCCUR. THE POWER UNIT MUST BE KEPT DRY. DAMAGE
TO POWER UNIT CAUSED BY WATER OR OTHER LIQUIDS SUCH AS
DETERGENTS, ACID ETC., IS NOT COVERED UNDER WARRANTY.
OPERATE LIFT ONLY BETWEEN TEMPERATURES OF 41 °- 104° F.
IMPROPER ELECTRICAL HOOK-UP CAN DAMAGE MOTOR AND WILL NOT
BE COVERED UNDER WARRANTY. PROTECT EACH CIRCUIT WITH TIME
DELAY FUSE OR CIRCUIT BREAKER. FOR 208-230 VOLT, THREE PHASE,
USE A 30 AMP FUSE. WHEN SELECTING A PLUG MAKE SURE YOU SELECT A
PLUG MADE FOR 30 AMP, 220 VAC, 3 PHASE POWER.
24VDC
380-460 VAC
