11
SECTION 4
(HYDRAULIC JACKING SYSTEM)
The PCL-18B employs a Hydraulic Jacking Dolly
System to move and position the Columns. The operation
of the Dolly System is similar to that of a pallet Jack.
(Fig. 4.1 & 4.2)
Moving the Columns
ENSURE THE DOORS OF THE ELECTRIC CONTROL
BOXES ARE CLOSED TO AVOID GETTING HANDS
PINCHED OR CRUSHED BY THE HANDLE BAR.
ALL LIFTING COLUMNS MUST BE LOWERED TO
THE GROUND BEFORE LIFTING OF ANY VEHICLE.
Fig. 4.2
Fig. 4.1
NEVER ATTEMPT TO MOVE A COLUMN WITH A
VEHICLE LOADED ON THE ARM FORKS.
DO NOT OPERATE THE LIFT WITH THE
HYDRAULIC JACK IN THE RAISED POSITION.
DO NOT STOP THE JACKING DOLLY ON SLOPE
1. Position the Release Handle in the Lowest position.
2. Pump the Handle Bar down and up several times to
raise the Column off the ground 1- 1.5” (25-38mm).
3. Position the Release Handle in the middle position.
4. Move the Column Assembly by pushing or pulling on
the Handle Bar.
5. When the Column is in the desired location, pull up
on the Release Handle and the Column will lower to the
ground.
