1.Long press power to turn it on.After full screen
display, the current electric field and magnetic
field value will be displayed,press power to turn
the backlight on. The screen will display“ ”.
Press it again to disable the backlight.If there is
no key operation, the backlight will turn off
automatically after 30 seconds. Long press power
to shut it down.If there is no key operation, the
instrument will shut down automatically after 5
minutes.
※Note:As there may be disturbance of
electromagnetic field in the environment,when
starting up,the instrument may give a small
reading. It is a normal phenomenon.
2.Hold the instrument with hand to make the
inductive zone at front end get closer to the
electromagnetic radiation source to be tested
slowly.If the actual radiation value is within the
technical index of the instrument,there will be a
value displayed;if the instrument has no reading,
it indicates that the electromagnetic radiation
value of the radiation source is smaller than the
minimum reading of the instrument,namely 1V/m
or 0. 01μT.
※Note:Distance measuring shall be made for
high-voltage facilities.Remember: stay safe.
3.During measurement, press“HOLD”to lock the
instrument reading.The“ ”will be displayed
on the screen.In case of unlocking, press“ ”
again.This instrument will produce a beep by
default after turning on and“ ”will be displayed
on the screen.Long press the“BEEP”to turn on
or off the beep.
4.By pressing“AVG/VPP”during measurement
under unlocking state, you can switch between the
average and the peak value.
5.If the figure displayed is unclear or the figure
flickers or the figure cannot be cleared, it
indicates that the battery runs out of power.
Please change the battery in time.
This radiation survey meter has the
following features：
One instrument with two uses,It can test the
electric field and the magnetic field radiation
at the same time;
Sound-light alarm,when the test result
exceeds the safe value,the instrument will
alarm automatically;
Data locking,one-key lock of the radiation value;
LCD graphic display of the radiation value trend;
Radiation assessment,remind you whether the
radiation value is safe or not;
Fashionable design,easy on-hand operation,it
is easy to move or make field measurement.
Electromagnetic radiation monitoring:
House and apartment,office,outdoor and
industrial site;
Electromagnetic radiation test:
Mobile phone, computer, TV set, refrigerator and
high voltage cable radiation test;
Radiation protection product test:
Test effects of radiation-proof clothes, radiation-
proof film and other prevention articles.
X-ray radiation index:★★★★★
Electric hair drier radiation index:★★★★★
Electric blanket radiation index:★★★★
Microwave oven radiation index:★★★★
Computer monitor and host radiation index:★★★
Mobile phone radiation index:★★
TV set radiation index:★★
Keyboard and mouse radiation index:★
Copying machine and printer radiation
index:★
Security check radiation index:★
Ele ctrom agnet ic Radi ation Te ste r
AVG
VPP
HOLD
BEEP
Version：GM3120-EN-00
Model: GM3120
Electromagnetic Radiation Tester
Instruction manual
Radiation survey meter can test electric field
radiation and magnetic field emission to reach
the optimal test result. It is used to test and learn
electromagnetic radiation situation indoor and
outdoor. It is equipped with a built-in
electromagnetic radiation sensor, which can
display the radiation value on LCD digital display
after processing by the control micro-chip. You
can make reasonable processing or taking
effective prevention measures toward the
electromagnetic radiation according to the test
result.
Influence and harms of electromagnetic
radiation on human body:
1.Being one of the causes of leukemia for
children;
2.Can cause cancer and accelerate proliferation
of cancer cells;
3.Can cause direct harm to human genital
system, nervous system and immune system;
4.Can cause mental disabilities of children and
diminution of vision, affect tissue development
and skeletal development of children;
5.Can cause diminution of hematopoietic
function of livers and even cause amotio retinae;
6.Being one of the main causes of cardiovascular
disease and diabetes;
7.Having bad influence on human visual system.
Moreover, strong electromagnetic radiation
may influence and destroy original bioelectric
current and biomagnetic field in human body and
cause abnormity of the original electromagnetic
field in human body. The elderly, children and the
pregnant are susceptible to electromagnetic
radiation.
Artificial electromagnetic radiation sources
include all kinds of electric appliances and
devices. By fair use of household appliances and
taking reasonable precautious measures,
electromagnetic radiation can be effectively
prevented and reduced.
II. Functions and features
VII. Technical parameters
I. Introduction
III. Range of application
VI. Radiation indexes
21 3
5 6
V. Operating instructions
4
VI. LCD display and key function
1. LCD full-screen display: see the following figure.
2. Names of components: see the following figure.
A. Inductive zone at front end
B.LCD display
C. Average/peak value
Unit
Precision
Range
Alarm threshold value
Reading display
Testing bandwidth
Sampling time
Test mode
Over range indication
Operating temperature
Operation humidity
Operating voltage
Power supply
Size
Weight
Electric field
V/m
1V/m
1V/m-1999V/m
40V/m
Magnetic field
μT
0.01μT
0.01μT-19.99μT
0.4μT
3-1/2-digit LCD
About 0.4 seconds
Bimodule synchronous test
LCD displays “1”
relative humidity＜80%
battery
5Hz—3500MHz
0℃~50℃
9V
6F22 9V
63. 6* 31* 125. 8mm
146g
B
A
C
D
E
F
Special declaration:
Our company reserves the right to modify the
product design and the instruction. We will not
give further notice for any changes!
D. Data locking/beep
E. Power
F. Battery door
Reference standards:
GB8702-1988 Regulations for Electromagnetic
Radiation Protection
HJ/T10.3-1996 Environmental Impact Assessment
Methods and standards on Electromagnetic Radiation
GB9175-88 Hygienic Standard for Environmental
Electromagnetic Waves
