Beninca BE.CODE User Manual

11
TECHNICAL DATA
Power supply
One 3V lithium battery (Li)
CR123A (1400mAh)
Range without obstacles 100m
Operating frequency 433,92 MHz
Operating temperature -20°C / +70°C
Number of storable codes 254
Protection level IP55
Overall dimensions see Fig.1
Wall installation (Fig. 2)
BE.CODE can be applied to wall through wash-
ers and plugs supplied.
WARNING: As the various programming phases
require an access to the radio receiver of the
system,itisadvisabletoxthekeypadtowall
only after programming all functions.
TheIP55protection level permits to use the
keypadalsoon walls that are not protected
against weather agents. It is however advisable,
wheneverpossible,toapplythesystemona
protected wall.
In any case, it is mandatory to apply the G
gasket between wall and container.
1Openthecontainerbylooseningthescrew
H.
2Applythe bottom of the container to wall
byusingeitherthetwoplugsTandthetwo
screwsC,ifamasonrysupportisprovided,
or self-tapering screws, if a metal support of
provided:inanycase,useaxingsuitable
to the support.
3 Close the container.
How to replace the batteries (Fig. 3)
OpenthecontainerbyremovingthescrewH,
Fig.2.
Abatteryremovablecoverissuppliedonthe
rearpart,xedwiththetwoscrewsY,Figure
3.
Alwaysreplacebothbatterieswithanewbat-
terieCR123A,takingcareofpoles.
Duration of the batterie
Thebatterylifealwaysdepends on thefre-
quencyof use. The following table indicates
the indicative life of batteries according to
their use:
No. of activations/day * Foreseen battery life** (years)
190 7
220 6
270 5
350 4
*Activations of around 10 seconds
**Average temperature: 25°C
PROGRAMMING
Before proceeding to the programming of the
system, some aspects of the operating princi-
ples must be highlighted.
Before programming, carefully read all instruc-
tions.
Access password
Theprogrammingofthe device is protected
byanaccesspasswordwhichshouldbeim-
mediatelycustomized.
Thefactory-presetpasswordis123456.
Take note of the new password and keep
it in a safe place for future uses. If the
password is lost, the device will have to be
entirely reset, and all memorised codes will
be removed.
Father Code / Child Code
BE.CODEbehavessubstantiallyasastandard
radio transmitter. It sends the receiver a code
whichis similar to the code that is sent by
pocketremotecontrols.
Foraneasier management of the system,
BE.CODE can store various digital codes from
thenumeric keypadandmatch themto one
single radio code.
111111
222222
333333
444444
555555
9999999
In this example, the “Father” code 999999
is matched to various “Child” codes
(1111111/222222/etc.).Inthisway,newChild
codescanbeincludedatanymomentbyacting
directlyonBE.CODE,withouthavingaccessto
the receiver.
Inanycase,theFathercodemustbestoredin
