Beninca DA.93AM - Dip-Switch Configuration; Trimmer Adjustments

6
7
The courtesy lamp switches off automatically after 150 seconds from the last operation being carried out.
The “automatic closure” function is inhibited until the OPEN push-button is pressed (closed contact).
Dip-switch functions
N.B.: Every change of functions have to be done without electricity.
DSW1= This selects the type of functioning of the P.P. button and Remote control.
Off= ”OPEN” - ”STOP” - ”CLOSE” - ”STOP” functioning
On= ”OPEN” - ”CLOSE” functioning.
DSW2= Selection of delayed motor 2 in the opening phase.
Off= 1 second
On= 3 seconds
DSW3= With this Dip-Switch the forewarning ashing is enabled or inhibited 4 seconds before each operation.
Off= Foreashing is inhibited
On= Foreashing is enabled
DSW4= With this Dip-Switch the electric lock is enabled or inhibited.
Off= Electric lock isnhibited
On= Electric lock is enabled
DSW5= It inhibits or enables the “stroke” function for the release of the electric lock. The function can be activated
only if the Dip-Switch “DSW4” is in position ON.
Off= Stroke inhibited
On= Stroke enabled
DWS6= The simultaneous start of the motors is inhibited or enabled (the times preset by Dip-Switch “DSW2”
and by trimmer TRAC are bypassed).
Off= Simultaneous starting inhibited
On= Simultaneous starting enabled
DSW7= Multiple-user function for blocks of ats: the “P.P.” and “PED” inputs control only the opening of the
system.
Off= ultiple-user function inhibited
On= Multiple-user function enabled
DSW8= It enables or inhibits the intervention of input “PED” during the closing phase of both motors.
Off= Inhibited
On= Enabled. In this case the “PED” input has the same function of the “P.P.” input, according to the
presettings of the Dip-Switch “DSW1”.
DSW9= Operating mode for ELS output (if enabled by Dip 4).
Off= ELS output is activated only when the closure is completed and the control unit is on.
On= ELS output is activated at every opening operation.
DSW10= It enables or inhibits the automatic closure.
Off= automatic closure is enabled
On= automatic closure is inhibited
For safety reasons this function is always inhibited after a “STOP” control signal is given and the control
unit hs been switched on.
Trimmer functions
TCA= It allows the regulation of the automatic closure when the Dip-switch “DSW10”= Off.
The adjustment varies from 10 sec. minimum to 4 minutes maximum.
The minimum time is obtained by turning the trimmer completely anticlockwise.
TL= It allows the adjustment of the operating time of the automatic system. When the time has elapsed the
software protection will be activated.
The adjustment varies from 5 sec. minimum to 100 sec. maximum.
The minimum time is obtained by turning the trimmer completely anticlockwise.
TRAC= It allows the adjustment of the motor 1 delay in the closing phase.
The adjustment varies according to the position of the “DSW2” Dip-Switch.
Off= from 1 sec. minimum to 12 sec. maximum
On= from 2 sec. minimum to 24 sec. maximum
The minimum time is obtained by turning the trimmer completely anticlockwise.
