TOM30M/TOM30ME/TOM3024E
a
X
(mm)
Y
(mm)
Z min
(mm)
K
(mm)
M max
(mm)
Opening Time
TOM30M-TOM30ME
(sec)
Opening Time
TOM3024ME
(sec)
90° 100 182,5 60 1070 110 18 11
90° 150 150 60 1023 25 18 11
102° 125 125 60 1048 25 18 11
100° 110 80 60 1065 50 14 8.5
110° 125 125 60 1049 70 16 10
104° 135 135 60 1038 70 17 10.4
98° 140 140 60 1033 80 18 11
92° 200 100 60 975 45 18 11
94° 145 145 60 1028 85 18 11
91° 175 125 60 999 65 18 11
90° 150 150 60 1023 90 18 11
TOM50M/TOM5024E
a
X
(mm)
Y
(mm)
Z min
(mm)
K
(mm)
M max
(mm)
Opening Time
TOM50M
(sec)
Opening Time
TOM5024ME
(sec)
90° 250 250 60 1315 150 30 18.3
103° 250 200 60 1320 150 30 18.3
100° 200 200 60 1370 130 26 15.9
105° 200 150 60 1373 90 24 14.6
110° 200 130 60 1374 65 23 14
120° 200 100 60 1374 45 23 14
90° 200 272,5 60 1362 200 30 18.3
90° 250 250 60 1315 125 30 18.3
105° 150 150 60 1423 25 23.5 14.4
Voor de gemarkeerde afmetingen hoeft de beugel P niet te worden gesneden
The highlighted dimensions do not require cutting the bracket P
