PARAMETERS, LOGICS AND SPECIAL FUNCTIONS
The following table describes the individual functions available in the control panel.
PARAMETRS (PAR)
MENU FUNCTION
MIN-MAX-(Default)
MEMO
tca
Automatic closure time Active only with “TCA”=ON logic.
At the end of the time set, the control panel commands a closure manoeuvre.
3-240-(40s)
tped
Adjusts the opening percentage of motor 1 (pedestrian function).
Value is expressed as a percentage (99% complete opening of the gate).
1-99 (50)
fso1
Adjusts the motor 1 OPENING speed during the normal phase.
Value expressed as a percentage.
50-99 (99%)
fsc1
Adjusts the motor 2 CLOSING speed during the normal phase.
Value expressed as a percentage.
50-99 (99%)
fso2
Adjusts the motor 2 OPENING speed during the normal phase.
Value expressed as a percentage.
50-99 (99%)
fsc2
Adjusts the motor 2 s CLOSING peed during the normal phase.
Value expressed as a percentage.
50-99 (99%)
slo1
Adjusts the motor 1 OPENING speed during the slowdown phases*.
Value expressed as a percentage.
10-50 (25%)
slc1
Adjusts the motor 1 CLOSING speed during the slowdown phases*.
Value expressed as a percentage.
10-50 (25%)
slo2
Adjusts the motor 2 OPENING speed during the slowdown phases*.
Value expressed as a percentage.
10-50 (25%)
slc2
Adjusts the motor 2 CLOSING speed during the slowdown phases*.
Value expressed as a percentage.
10-50 (25%)
tdmo
Mot.2 opening delay time
Adjusts the delay time in opening of motor 2 compared to motor 1
0-15-(2s)
tdmc
Mot.1 closure delay time
Adjusts the delay time in closure of motor 1 compared to motor 2
0-40-(3s)
tsm1
Adjusts the slowdown phase in the opening and closing of the M1 motor.
Value expressed as a percentage on the entire run.
1-99 (20%)
tsm2
Adjusts the slowdown phase in the opening and closing of the M2 motor.
Value expressed as a percentage on the entire run.
1-99 (20%)
pmo1
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the opening phase at normal speed - Motor 1
1-99-(30%)**
pmc1
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the closure phase at normal speed - Motor 1
1-99-(30%)**
pmo2
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the opening phase at normal speed - Motor 2
1-99-(30%)**
pmc2
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the closure phase at normal speed - Motor 2
1-99-(30%)**
pso1
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the opening phase at slowdown speed - Motor 1
1-99-(30%)**
psc1
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the closure phase at slowdown speed - Motor 1
1-99-(30%)**
pso2
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the opening phase at slowdown speed - Motor 2
1-99-(30%)**
psc2
Adjusts the intervention threshold of the anti-crushing device* (amperometric sensor)
during the closure phase at slowdown speed - Motor 2
1-99-(30%)**
tls
SERL (Service light) enabling time outputs AUX1/AUX2.
On each manoeuvre, the contact closes for the time set.
See connection screen Figure 5/6
1-240-(60s)
t2ch
Enabling time of outputs AUX1/AUX2 when set as second radio channel.
0: Bistable output, the status of the output switches on each command received.
1-250: switching time in seconds
0-250-(1s)
tloc
Electric lock enabling time.
Value expressed in 1/10s (0=0s - 50=5s)
0-50
(10=1s)
vloc
Electric lock power supply voltage.
0: 12V - 1:24V
0-1-(0)
