Beninca TRUST24 - Page 11

21
EN
sasc
Sets a short inversion once the closure limit switch point has been reached.
It may be useful to facilitate the manual release of the gate.
Value expressed in 1/10 (0=0s - 40=4s)
0-40 (10)
saso
Sets a short inversion once the opening limit switch point has been reached.
It may be useful to facilitate the manual release of the gate.
Value expressed in 1/10 (0=0s - 40=4s)
0-40 (5)
seav
Adjusts the intervention threshold of the anti-crushing device (encoder) during the
phase at normal speed.
0:Off -1: minimum sensitivity - 99: maximum sensitivity
0-99-(1%)
sear
Adjusts the intervention threshold of the anti-crushing device (encoder) during the
slowdown phase*.
0:Off -1: minimum sensitivity - 99: maximum sensitivity
0-99-(1%)
aux1
Configures the AUX1 output operating mode.
0: SCA output (default)
1: radio 2ch output
2: courtesy light output (based on the time set by TLS parameter). See Fig.5
3: zone light output (always on with motor in motion and during TCA count). See Fig.5.
4: Photo-test Used to power the transmitters of the photocells in TEST mode.
5: Flashing output, copies the behaviour of the BLINK output
6: Alarm output. If the photocells remain engaged for over double the TCA set time,
the contact closes.
ATTENTION!! The 24Vdc LED lamps, due to inrush current, cannot be directly connected
to the AUX outputs, use a decoupling relay.
0-6 (0)
aux2
Configures the AUX2 output operating mode.
0: SCA output (default)
1: radio 2ch output
2: courtesy light output (based on the time set by TLS parameter). See Fig.6
3: zone light output (always on with motor in motion and during TCA count). See Fig.6.
4: Photo-test Used to power the transmitters of the photocells in TEST mode.
5: Flashing output, copies the behaviour of the BLINK output
6: Alarm output. If the photocells remain engaged for over double the TCA set time,
the contact closes.
ATTENTION!! The 24Vdc LED lamps, due to inrush current, cannot be directly connected
to the AUX outputs, use a decoupling relay.
0-6 (1)
* ATTENTION: FURTHER SETTING OF THESE PARAMETERS CAN BE DANGEROUS.
COMPLY WITH LEGISLATION IN FORCE!
With the motors without a limit switch and/or encoder, adjust the sensitivity of the sensor that causes stoppage during the
slowdown phase.
** 1: minimum force/torque - 99: maximum force/torque.
The control panel avails of two anti-crushing devices: the amperometric sensor (adjusted by parameters PMO1/2-PMC1/2-PSO1/2-
PSC1/2) and the encoder (adjusted by the SEAV and SEAR parameters).
Using the Autoset procedure, the sensitivity of the amperometric sensor is adjusted by default, while the encoder (with default setting)
only activates if the gate stops completely following impact.
You are advised to only use a system at a time, giving preference to the amperometric sensor, whose response time is less.
LOGIC (LOG)
MENU FUNCTION
ON-OFF-
(Default)
MEMO
TCA
Enables and disables automatic closure.
On: automatic closure enabled.
Off = automatic closure disabled
(ON)
IbL
Enables or disables the shared function.
On: shared function enabled. The S.S. or transmitter impulse has no effect during the
opening phase.
Off: apartment complex function disabled.
(OFF)
ibca
Enables or disables the condominium function during TCA counting.
On: apartment complex function enabled. The PP or transmitter pulse has no effect during
TCA counting.
Off: apartment complex function disabled.
(OFF)
PP
Select the operating mode of the ”P.P. button” and the transmitter.
On: “Operation”; OPEN> CLOSE > OPEN>
Off: “Operation”; OPEN>STOP>CLOSE>STOP>
(OFF)
pre
Enables or disables pre-flashing.
On: Pre-flashing enabled. The flashing light activates 3s before the motor starts.
Off: Pre-flashing disabled.
(OFF)
