Beninca TRUST24 - Page 12

22
SCL
Enables and disables rapid closure.
On: rapid closure enabled. With the gate open or in the opening phase, intervention of the
photocell causes automatic closure 3 s after complete opening. Active only with TCA:ON
Off = rapid closure disabled
(OFF)
htr
Person present function enabled or disabled.
On: Person Present Operation
The APRE/CHIUDE button must be kept pressed throughout the manoeuvre. Opening the
STOP input stops the motor. All the safety inputs are disabled.
Off: Automatic/semi-automatic operation.
(OFF)
LTCA
Selection of the flashing light operating mode during the TCA time
On: Flashing indicator light on during TCA
Off: Flashing indicator light off during TCA
(OFF)
MBLK
Sets the BLINK flashing output operating mode.
On: The output provides intermittent voltage during the manoeuvre phase (2 flashes per
second).
Off: The output provides continuous voltage during the manoeuvre phase.
(OFF)
TST1
Enables or disables the photocells check on the PHOT Op input, enabled both in closure
and in opening.
On: Check enabled. If the check has a negative outcome, no manoeuvre is commanded.
See Fig.5/6 - “PHOTO TEST”. (AUX=4)
Off: Check the photocells on each disabled manoeuvre. This setting requires maintenance
of photocells every 6 months.
(OFF)
tst2
Enables or disables the photocells check on the PHOT Cl input, enabled both in closure
and in opening.
On: Check enabled. If the check has a negative outcome, no manoeuvre is commanded.
See Fig.5/6 - “PHOTO TEST”. (AUX=4)
Off: Check the photocells on each disabled manoeuvre. This setting requires maintenance
of photocells every 6 months.
(OFF)
tst3
Enables or disables the BAR input TEST.
Activation of the TEST function is only possible using items SC.RF and RF/RF.SUN, consult
the specific instructions.
On: Check enabled. If the check has a negative outcome, no manoeuvre is commanded.
See Fig.4 - “BAR TEST”. (AUX=4)
Off: Test disabled.
(OFF)
phcl
Selection of the PHOT CL input operating mode.
On: PHOT CL input enabled only in closure.
In closure: opening of the contact causes stoppage of the motor and instantaneous inver-
sion of the running direction (opens).
Off: Active PHOT CL input both in closure and opening.
In opening: opening of the contact caused by stoppage of the motor, when the photocell
is free, motor opening restarts.
In closure: opening of the contact causes stoppage of the motor, when the photocell is free,
the motor running direction inverts (opens).
(OFF)
1mot
Selection of the motors 1 or 2 operating mode.
On: Use for a single motor, connected to output M1
Off: Use for two motors.
(OFF)
minv
Motors start order:
On: motor 2 starts first in opening.
Off: motor 1 starts first in opening.
(OFF)
aopf
Enables or disables the “Forced opening function without mains) function (can only be
enabled with the emergency batteries connected and working).
On: Function enabled. In the event of a power cut, before the emergency battery goes
completely flat, the control panel forces an opening manoeuvre.
The automation remains open until the mains power supply is restored.
Off: Function not enabled.
(OFF)
ham
Enables or disables inversion strike.
On: Function enabled. Before each opening movement, the control panel commands a 2s
movement in the opposite direction to facilitate release of the solenoid valve.
Off: Function disabled.
(OFF)
blco
Enables or disables the block in opening function.
On: Block function enabled. .
Off: Block function disabled.
(OFF)
