RESET (RES)
Control panel RESET ATTENTION!: It returns the control panel to the default values.
Pressing the <PG> button for the first time causes the RES message to flash; pressing the <PG> button again resets the control panel.
Note: The transmitters are not deleted from the receiver or the access password.
All the logic and all the parameters are brought to the default values and it is therefore necessary to repeat the autoset procedure.
AUTOSET (AUTO)
This function is used to set the optimal automation operating values and, at the end of the procedure, the parameters of DISPLACE-
MENT, WORKING TIME and SLOWDOWN are adjusted.
To autoset, proceed as follows:
Ensure that there are no obstacles in the operating area of the gates, if necessary, cordon off the area to prevent access to people,
animals, cars, etc.
During the autoset phase, the anti-crushing function is not active.
b) Select the AUTO function and press OK.
c) Select with the button <+> or <-> the sub-menu nLSu, LSU or ENC according to the presence of the limit switch and/or encoder:
nLSu: if the motor is without a limit switch and encoder
LSU: if the motor is equipped with a limit switch and encoder
ENC: if the motor is equipped with an encoder and without a limit switch.
d) having selected the item, press OK to start the autoset phase.
The central panel executes a series of manoeuvres for learning of the gate stroke and for configuration of the parameters.
Initially both the gates are brought to the opening position, then after a few opening and closure manoeuvres at different speeds, of
one or both gates, the control panel displays the message OK. If the operation does not have a positive outcome, the ERR message
is displayed. Repeat the operation after checking the wiring and the presence of obstacles
During the manoeuvres, the display shows each code: OPEN during opening of motor 1 or 2 and CLOS during closure of motor 1 or 2.
PASSWORD (CODE)
It allows you to enter the access protection code to control panel programming.
You can enter an alphanumerical code of four characters using the numbers from 0 to 9 and the letters A-B-C-D-E-F.
The default value is 0000 (four zeros) and indicates the absence of the protection code.
At any time, you can cancel the code entering operation, pressing the + and - keys simultaneously. Once the password is entered,
you can operate the control panel, entering and exiting programming for a time of approx. 10 minutes, to allow the adjustment and
test operations of the functions.
By replacing the code 0000 with any other code, you enable protection of the control panel, preventing access to all the menus.
If you want to enter a protection code, proceed as follows:
- select the Code menu and press OK.
- the code 0000 is displayed, even if a protection code has already been previously entered.
- use the + and - keys to change the value of the flashing character.
- the OK key confirms the flashing character and moves on to the next one.
- after entering the 4 characters, a “CONF” confirmation message appears.
- after a few seconds, the code 0000 is displayed again.
- it is necessary to reconfirm the previously entered protection code in order to avoid unintentional entries.
If the code corresponds to the previous one, an “OK” confirmation message is displayed.
The control panel automatically exits the programming phase and to access the menu again, the saved protection code will be neces-
sary.
IMPORTANT: NOTE the protection code and KEEP IT IN A SAFE PLACE for future maintenance. To remove a code from a
protected control panel, you should enter programming with the password and bring the code to the default value 0000.
IF THE CODE IS LOST, IT IS NECESSARY TO CONTACT THE AUTHORISED TECHNICAL
SERVICE CENTRE FOR A TOTAL RESET OF THE CONTROL PANEL.
TRANSMITTERS REMOTE LEARNING
If you have a transmitter already stored in the receiver, it is possible to carry out radio remote learning (without having to access the
control panel).
IMPORTANT: The procedure must be carried out with the gate in opening during the TCA pause or the gate open if the TCA
logic is OFF. The REM logic must be ON.
Proceed as follows:
1 Press the hidden key of the transmitter already stored.
2 Press, within 5s, the key of the transmitter already stored corresponding to the channel to associate with the new transmitter. The
flashing light comes on.
3 Press, within 10s, the hidden key of the new transmitter.
4 Press, within 5s, the key of the new transmitter to associate with the channel chosen in point 2. The flashing light goes out.
5 The receiver memorises the new transmitter and immediately exits programming.
FUSES AND GUARDS
F1: T4A - Main safety fuse.
F2: Resettable safety fuse for accessories power supply output.
Intervenes in the event of overload or short circuit on 24 Vdc output. In this case, disconnect the control panel and check the connec-
tions or the quantity of accessories connected to the 24Vdc output. Once the connections are reset in correct mode, the accessories
power supply output will automatically start working again.
