You should check your vacuum cleaner’s rotating floor brush and drive belt regularly for wear
or damage. You should also clean the brush and brush ends of string, hair and carpet fibers.
This type of debris can wrap around the brush and hamper its ability to effectively clean your
carpet. Also remove any debris that has accumulated under the brush cover.
CHECK ROTATING FLOOR BRUSH & DRIVE BELT
This product is intended for household use only and not for commercial
or industrial use. Vacuuming of dust from products like plaster, concrete
or ashes will damage the motor and void the guarantee.
To reduce the risk of injury from moving parts, first turn the vacuum cleaner
off and disconnect the power plug from the electrical outlet.
NOTICE:
!
WARNING:
!
1
1. Remove the 2 small rollers with a flat
head screwdriver
2. Remove the 2 screws underneath the
rollers with a Phillips screwdriver
3. Gently lift off the plastic base cover
4. Clean any string, hair and other
debris from the rotating floor brush,
paying particular attention to the
brush ends
5. Clean string, hair and other
debris from the motor pulley and
drive belt areas
6. Check the drive belt carefully
for wear, cuts or stressed areas.
Replace the drive belt if damaged.
See page (15) for spares details
7. Check air passageway for
obstructions. Remove debris
from this area
8. When clean, replace the plastic base
cover, screws and rollers before using
the machine
4 - 73
Drive belt
Air Passageway
Brush
