DSP 2500 Inverter System
10.15.07 15 028-0009-200
Tebevert DSP (120/240VAC @ 2500VA)
The inverter module features DSP controlled high frequency, switch mode PWM
technology. The module converts the incoming DC voltage to computer grade
120/240VAC 60Hz power for use by the connected customer equipment.
DC Input
Nominal DC voltage: 48 VDC
Permissible deviation from the rated value: +20%; -15%
Input current at nominal real power
Rated voltage 100%: (48V) 47.0 A
Overvoltage 120%: (48V x 1.2V) 39.0 A
Undervoltage 85%: (48V x .85V) 55.0 A
Input current at no load operation at rated voltage: 1.4 A
Permissible ripple of input voltage: 5% eff.
Breaker or fuse requirement 70 AMP
AC Output
Alternating voltage: 120 VAC
Static voltage tolerance: 1%
Rated power (cos =0, 8): 2.5 kVA (total)
Nominal real power: 2.0 kW (total)
Rated current: (cos =0, 8) 20.8/10.4A @ 120/240VAC
Maximum Load Imbalance No greater than a +/- 10% L1 to L2 imbalance
Short-circuit behavior: >6000VA (total) for 4 s, after that cut-off
(DIN VDE 0100 - 410)
Overload behavior: 2xI
N
for 4 s, after that reduction to 1.2xI
N
for 60s,
after that unit turns off
Overload capacity-permanent: 1.1xI
N
(total)
Crest factor: 2.8
max. peak current 2.8xI
N
, the permissible effective
nominal current decreases in case of higher crest
factor
Frequency: 60Hz
