DSP 2500 Inverter System
10.15.07 25 028-0009-200
14. Configuration Index
DSP25F-ABCCDE
Variable
Description
A
Output Voltage Configuration
1
120VAC @ 60Hz
2
240VAC @ 60Hz
3
120/240VAC @ 60Hz
4
230VAC @ 50Hz
B
Parallel/Relay Bypass Configuration
1
Stand Alone Module
2
Parallel Unit Connections Module
3
AC Mains Relay Bypass for 120VAC AC Mains (Future)
CC
Output Group #1 Configuration
01
Three NEMA 5-15R 120VAC Output Receptacles w/15A Push to Reset Circuit
Breaker
02
Three NEMA 5-20R 120VAC Output Receptacles w/20A Push to Reset Circuit
Breaker
03
One 120VAC Hardwire Terminal Block with 30A Circuit Breaker
04
One 120VAC NEMA L5-30R Twist Lock Outlet with 30A Circuit Breaker
2
05
Two IEC 320-C13 Output Receptacles w/15A Push to Reset Circuit Breaker
06
Two IEC 320-C19 Output Receptacles w/20A Push to Reset Circuit Breaker
07
One 240VAC Hardwire Terminal Block with a Two-Pole 20A Circuit Breaker
2
Requires an empty panel in Output Plate #2 Configuration.
