DSP 2500 Inverter System
10.15.07 26 028-0009-200
08
One 230VAC Hardwire Terminal Block with a Single-Pole 20A Circuit Breaker (L-
N)
09
One 240VAC NEMA L6-20R Twist Lock Outlet with a Double-Pole 20A Circuit
Breaker
3
10
One 120/240VAC Hardwire Terminal Block with Double-Pole 20A Circuit Breaker
4
11
One 120/240VAC NEMA L14-20R Twist Lock Outlet with Double-Pole 20A Circuit
Breaker
5
D
Output Group #2 Configuration
0
Empty
1
Blank Panel
2
Three NEMA 5-15R 120VAC Output Receptacles w/15A Push to Reset Circuit
Breaker
3
Three NEMA 5-20R 120VAC Output Receptacles w/20A Push to Reset Circuit
Breaker
4
Two IEC 320-C13 Output Receptacles w/15A Push to Reset Circuit Breaker
5
Two IEC 320-C19 Output Receptacles w/20A Push to Reset Circuit Breaker
E
Faceplate
0
Benning
1
Reserved
2
Benning with Two 120VAC NEMA 5-15R Output Receptacles w/15A Push to
Reset Circuit Breaker
6
3
Requires an empty panel in Output Plate #2 Configuration.
4
Requires an empty panel in Output Plate #2 Configuration.
5
Requires an empty panel in Output Plate #2 Configuration.
