BenQ BL2420 User Manual

14 How to assemble your monitor hardware
Tighten the thumbscrew on the bottom of the monitor
base as illustrated.
Orient and align the stand arm with the monitor ( ),
push them together until they click and lock into place
().
Gently attempt to pull them back apart to check that
they have properly engaged.
Carefully lift the monitor, turn it over and place it
upright on its stand on a flat even surface.
You might want to adjust the monitor stand height. See
Adjusting the monitor height on page 22 for more
information.
You should position the monitor and angle the screen to
minimize unwanted reflections from other light sources.
2
1
1
1
2
2

BenQ BL2420 Specifications

General

Panel Type	IPS
Aspect Ratio	16:9
Refresh Rate	60 Hz
Response Time	5 ms (GtG)
Brightness	250 cd/m²
Contrast Ratio	1000:1
Dynamic Contrast Ratio	20, 000, 000:1
VESA Mount	100 x 100 mm
Viewing Angles	178° horizontal / 178° vertical
Color Support	16.7 million colors
Inputs	D-Sub, DVI, HDMI, DisplayPort
