39 Navigating the main menu
For models without D-Sub inputs
Input Use this to change the input to that appropriate to
your video cable connection type.
Available options vary by model. Check the
Specifications document on the provided CD for
available input connectors of the purchased model.
•D-Sub
•DVI
•HDMI
•DisplayPort
H. Position Adjusts the horizontal position of the screen image. 0 to 100
V. Position Adjusts the vertical position of the screen image. 0 to 100
Pixel Clock Adjusts the pixel clock frequency timing to
synchronize with the analog input video signal.
See also: Picture optimization (for models with
D-Sub inputs) on page 35.
Not applicable to a digital input signal.
0 to 100
Phase Adjusts the pixel clock phase timing to synchronize
with the analog input video signal.
See also: Picture optimization (for models with
D-Sub inputs) on page 35.
Not applicable to a digital input signal.
0 to 63
Item Function Range
Item Function Range
Auto Pivot Sets to rotate the display with the monitor. See page
23 for more information.
•ON
•OFF
Input Use this to change the input to that appropriate to
your video cable connection type.
•DVI
•HDMI
•DisplayPort
To Next Page
