Guideline to AV box
Features and Connection
AV Connection Port
This box is compatible with RCA input, S-Video input and audio output.
Figure 29 Connection of AV box
Speaker
RCA Jack
For Video and Audio Input from VHS or V8
S Video Port
For S-Video Input
*AV box is sold separately and is not included in the standard configuration of accessories in
the unit. Please contact the dealer if you need the box or visit our web site for more
information.
AV Control Pad
Source
Select the source
Volume up
Turn the volume upward
Volume down
Turn the volume downward
