29 How to adjust your monitor
Video source selection in PIP/PBP mode
Your monitor scans for the available video sources in the following order: HDMI, DP, and
USB-C™, and displays the first available one. This video source will become the main source in
PIP/PBP mode. You will need to decide the second source for PIP/PBP mode from the menu in
PIP/PBP source on page 32. Menu options that are not available will become grayed out.
Refer to the following table to find your main source and its supporting second sources. To find
out the supported incoming display mode (input timing), please read the "Preset display
modes
" section from the link "Adjusting the Screen Resolution" on the CD.
Possible second sources
Inputs
HDMI-1 HDMI-2 DP USB-C™
Main
source
HDMI-1 VVV
HDMI-2 V V V
DP V V V
USB-C™ V V V
