BenQ EX Series User Manual

32 Navigating the main menu
Mode Sets the PIP or PBP mode.
PIP: the Picture-in-Picture (PIP) mode
displays the main video source on the screen
while the second source in an inset window.
PBP: Allows to display images from two
different video sources side-by-side.
OFF: Disables PIP/PBP mode.
• PIP
• PBP
• OFF
PIP/PBP
source
Sets the second video source for the PIP/PBP
mode.
• HDMI 1
• HDMI 2
• DisplayPort
• USB-C
SWAP Videos from the main and the second sources
are swapped on the screen.
PIP Size Determines the size of the inset window in
the PIP mode.
• Small
• Medium
• Large
PIP Position Adjusts the position of the inset window in
the PIP mode.
• Top Right
• Top Left
• Bottom
Right
• Bottom Left
Input Use this to change the input to that appropriate to your
video cable connection type.
• HDMI 1
• HDMI 2
• DisplayPort
• USB-C
Item Function Range
