BenQ GL950A Service Manual

42
Display Timing Table
Note:
P: Preset Mode
NP: None Preset Mode
FS: Fail Save Mode (show “out of range”, but still can see picture)
O: Out of Range (only show “out of range”, without picture)
BenQ
Preferred
Mode
Number
1366x768 1440x900 1600x900 1680x1050 1920x1080 Resolution
Pixel
clock
(unit: MHz)
H-sync
(
unit: kHz
)
V-sync
(unit:
Hz)
IDF-1 P P P P P 640x350 25.18 31.47 70.09
FS FS FS FS FS 640x350 31.50 37.86 85.08
NP NP NP NP NP 640x400 25.18 31.47 70.09
FS FS FS FS FS 640x400 31.5 37.86 85.08
NP NP NP NP NP 640x480 30.24 35.00 66.67
DMT-1 P P P P P 640x480 25.17 31.47 59.94
NP NP NP NP NP 640x480 31.50 37.86 72.8
DMT-2 P P P P P 640x480 31.50 37.50 75.00
DMT-3 FS FS FS FS FS 640x480 36.00 43.27 85.01
NP NP NP NP NP 640x500 25.25 31.00 57.76
IDF-2 P P P P P 720x400 28.32 31.47 70.08
FS FS FS FS FS 720x400 35.5 37.93 85.04
P P P P P 832x624 57.27 49.71 74.53
BenQ NP NP NP NP NP 800x480 29.5 29.74 59.476
NP NP NP NP NP 800x600 36.00 35.16 56.25
DMT-4 P P P P P 800x600 40.00 37.88 60.32
NP NP NP NP NP 800x600 50.00 48.08 72.19
DMT-5 P P P P P 800x600 49.50 46.88 75.00
DMT-6 FS FS FS FS FS 800x600 56.25 53.67 85.06
DMT-26 NP NP NP NP NP 848x480 33.75 31.02 60.00
NP NP NP NP NP 848x480 31.50 29.83 59.66
NP NP NP NP NP 848x480 37.52 35.00 70.00
NP NP NP NP NP 848x480 39.25 36.07 72.00
NP NP NP NP NP 848x480 41.00 37.68 74.77
NP NP NP NP NP 720x576 32.71 35.910 59.950
BenQ P P P P P 1024x576 46.966 35.82 60
BenQ P P P P P 1024x600 48.964 37.32 60
FS FS FS FS FS 1024x768-I 44.9 35.52 43.48
DMT-7 P P P P P 1024x768 65.00 48.36 60.00
NP NP NP NP NP 1024x768 75.00 56.48 70.07

BenQ GL950A Specifications

General

3D	No
HD type	-
Pixel pitch	0.3 x 0.3 mm
Aspect ratio	16:9
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	12000000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1366 x 768
AC (power) in	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Number of OSD languages	17
Panel mounting interface	100 x 100 mm
Power consumption (standby)	0.3 W
Power consumption (typical)	15 W
Product color	Black
Package depth	365 mm
Package width	116 mm
Package height	518 mm
Package weight	4300 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	163.9 mm
Height (with stand)	362.15 mm
Depth (without stand)	57 mm
Width (without stand)	459.49 mm
Height (without stand)	282.29 mm
Weight (without stand)	2900 g
