BenQ GL950A Service Manual

8
3. General Description
This new LCD (Liquid Crystal Display) monitor BenQ GL950A/GL950AM/G950A/G950AM offers numerous features
and functions, for example:
 Panel Type: TN + LED (GL950A/GL950AM)
 Panel Type: TN + CCFL (G950A/G950AM)
 Minimal space requirements thanks to slim casing
 Contrast ratio 12 million:1 (DCR), brightness 250nits (GL950A/GL950AM)
 Contrast ratio 50000:1 (DCR), brightness 200nits (G950A/G950AM)
 MAX. resolution: 1366X768
 Viewing Angle (H/V), CR≧10: 170/160 (GL950A/GL950AM)
 Viewing Angle (H/V), CR≧10: 90/65 (G950A/G950AM)
 Presentation of up to 16.7 M colors (in conjunction with an appropriate graphics card)
 Automatic scanning of horizontal frequencies from 30 to 83 kHz and refresh rates (vertical frequencies) from 50
to 76 Hz (absolutely flicker-free)
 Digital screen controller with microprocessor for storing 15 different display modes
 Freely adjustable color alignment for matching the screen colors to the colors of various input and output devices
 Convenient operation via integrated OSD (On-Screen-Display) menu
 VESA-DDC compatibility
 Plug & play capability
 Power management for reducing power consumption when the computer is not in use
This operating manual contains important information you require to start up and run your LCD monitor.
This specification defines the requirements for the 18.5″ MICROPROCESSOR based Multi-mode supported high
resolution color LCD monitor. This monitor can be directly connected to general 15-pin VGA connector and supports
VESA DPMS power management and plug & play function.
Additional information
Due to the nature of liquid crystal display (LCD) technology, the picture resolution is always fixed. For the best
display performance, please set the display resolution to 1366X768 pixels with an aspect ratio of 16:9. This is called
“Native Resolution” or maximal resolution - that is, the clearest picture. Lower resolutions are displayed on a full
screen through an interpolation circuit. Image blurring across pixel boundaries can occur with the interpolated
resolution depending upon the image type and its initial resolution.
4. Related service information
This Service Manual contains general information. There are 2 levels of service:
Level 1: Cosmetic / Appearance / Alignment Service
Level 2: Circuit Board or Standard Parts Replacement
Service Web Site
eSupport URL: http://esupport.benq.com

BenQ GL950A Specifications

General

3D	No
HD type	-
Pixel pitch	0.3 x 0.3 mm
Aspect ratio	16:9
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	12000000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1366 x 768
AC (power) in	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Number of OSD languages	17
Panel mounting interface	100 x 100 mm
Power consumption (standby)	0.3 W
Power consumption (typical)	15 W
Product color	Black
Package depth	365 mm
Package width	116 mm
Package height	518 mm
Package weight	4300 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	163.9 mm
Height (with stand)	362.15 mm
Depth (without stand)	57 mm
Width (without stand)	459.49 mm
Height (without stand)	282.29 mm
Weight (without stand)	2900 g
