69
C823 4.7uF 25V
R828
6.2M OHM 1/2W
R837
7K5 1/10W 5%
+
C804
1000uF 25V
C819
JUMPER
Q806
APM4548AK
1
2
3
4 5
6
7
8
S2
G2
S1
G1 D1
D1
D2
D2
+5Vi
R812
100K 1/8W 5%
R823
2.2K
R819 2R2 1/8W 5%
C818
2.2UF 16V
R802
22R 1/8W 5%
D803
BAV99
3
1
2
C810
0.0022uF
C801
47NF/50V
R807
10K 1/10W 5%
C809
220pF
R813
100K 1/10W 5%
C813
NC
R803
5K1 1/8W 5%
R817
2.2 OHM 1/4W
R811
82 KOHM +-1% 1/8W
C802
47NF/50V
R820
10 OHM +-5% 1/10W
R821
10 OHM +-5% 1/10W
R818 2R2 1/8W 5%
LV3
CN801
CONN
1
2
R810
75KOHM +-1% 1/4W
R808
470R 1/10W 1%
R822
2.2K 1/4W
CN803
CONN
1
2
Q802
2N7002 SOT-23
R836
56KOHM +-5% 1/10W
C817
2PF 6KV
R806
100K 1/10W 5%
R815
3.6K 1%
R801
10K 1/8W 5%
ON/OFF
+16V
LV1
C803
0.1uF
DIM
R830
7.5KOHM +-1% 1/8W
ZD802
RLZ5.6B
1 2
ZD803
RLZ5.6B
1 2
C814
220pF
C805
0.022uF
C824 4.7uF 25V
D801
IN4148
R814
20KOHM +-1% 1/8W
C815
0.1uF/50V
IC801 ta9687GN-A-0-TR
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
VSEN
SSTCMP
CT
RT1
GNDA
PDR2
GNDP
NDR2NDR1
PDR1
VDDA
TIMER
PWM
ISEN
OVPT
ENA
PT801
POWER X'FMR
6
2
7
5
1 8
D806
BAV70
3
1
2
C811
0.1uF/50V
C807
3.3NF
C808
0.033uF
R816 2.2 OHM 1/4W
R809
1M 1/10W 5%
Q805
APM4548AK
1
2
3
4 5
6
7
8
S2
G2
S1
G1 D1
D1
D2
D2
C812
NC
R804
5K1 1/8W 5%
C806
2.2UF 16V
C821
JUMPER
