BenQ GL950A Service Manual

74
Key Board
715G5048K0C000004I
ZD001NC/UDZSNP5.6B
1 2
GND
R007 0R05OHM1/8W
SW001
POWER
MENU
GND
GND
SW003
SW
34
2 1
5
6
LED001
LED
2 4
1 3
(ENTER)
LED_GRN#
SW004
R004 1K 1/8W 1%
C
11Wednesday , June 15, 2011
715G0000-A
01.KEY BOARD
G5048-C-X-X-2-110603
OEM MODEL Size
Rev
Date
Sheet
of
TPV MOD EL
PCB NAME
称爹
T P V ( Top Victory Elect ronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
GND
DC_POWERON
ZD006
NC/UDZSNP5.6B
1 2
GND
GND
SW002
SW
34
2 1
5
6
GND
(AUTO)
SW006SW003
GND
ENTER
LED_GRN#
SW005
SW
34
2 1
5
6
GND
LBADC1
(Power)
AUTO
CN001
CONN
1
2
3
4
5
6
7 8
ZD007
NC/UDZSNP5.6B
1 2
GND
R002 3K 1/8W +/-1%
SW006
SW
34
2 1
5
6
GND
GND
GND
ZD004NC/UDZSNP5.6B
1 2
ZD002NC/UDZSNP5.6B
1 2
LED_RED#
GND
GND
SW002
GND
R005 3K 1/8W +/-1%
ZD005NC/UDZSNP5.6B
1 2
RIGHT
(LEFT)
GND
(RIGHT)
SW001
SW
34
2 1
5
6
GND
LEFT
GND
GND
LBADC2
ZD003NC/UDZSNP5.6B
1 2
GND
GND
SW005
ZD008
NC/UDZSNP5.6B
1 2
LED_RED#
R003 1K 1/8W 1%
R008
9K1 1/8W 1%
B
LED001
SW004
SW
34
2 1
5
6
(MENU)

BenQ GL950A Specifications

General

3D	No
HD type	-
Pixel pitch	0.3 x 0.3 mm
Aspect ratio	16:9
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	12000000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1366 x 768
AC (power) in	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Number of OSD languages	17
Panel mounting interface	100 x 100 mm
Power consumption (standby)	0.3 W
Power consumption (typical)	15 W
Product color	Black
Package depth	365 mm
Package width	116 mm
Package height	518 mm
Package weight	4300 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	163.9 mm
Height (with stand)	362.15 mm
Depth (without stand)	57 mm
Width (without stand)	459.49 mm
Height (without stand)	282.29 mm
Weight (without stand)	2900 g
