BenQ LH770 - Heat Radiation Notice; Ventilation Guidelines

English
9
Laser indication
The following diagram shows the location of laser aperture. Be aware that you must not look straight at
the laser.
Laser aperture
Heat radiation notice
Leave a space at least 500 mm (19.7 in.) around the air outlet. Make sure that no object blocks the
ventilation within 300 mm (11.8 in.).
Keep the air vent at least 1 m away from the air inlet of other projectors.
Air inletAir outlet
