9 Introduction
Controls and functions
Projector & Remote control
1. POWER
Toggles the projector between standby mode
and on.
ON/ Off
Toggles the projector between standby mode
and on.
2. POWER indicator light/TEMPerature
warning light/LAMP indicator light
(See Indicators on page 41.)
3. IR remote sensor
4. BACK
Goes back to previous OSD menu, exits and
saves menu settings.
5. Arrow keys ( , , , )
When the On-Screen Display (OSD) menu is
activated, these keys are used as directional
arrows to select the desired menu items and
to make adjustments.
Keystone keys ( , )
Displays the keystone correction page.
Volume keys /
Decreases or increase the projector volume.
2
9
7
6
8
5
1
3
4
10
All the key presses described in this document
are available on the remote control or projector.
1
4
7
8
18
17
10
19
20
21
23
22
16
11
12
6
14
15
13
9
