8 Introduction
Projector exterior view
1. Focus ring and Zoom ring
2. Vent (air exhaust)
3. Adjuster feet
4. Projection lens
5. IR remote sensor
6. External control panel
(See Controls and functions on page 9.)
7. Lamp cover
8. Vent (air inlet)
9. Audio input jacks
Audio output jack
10. HDMI 2 input port
11. HDMI 1/MHL input port
12. USB Type A port
13. RGB (PC) signal input jacks
14. RGB (PC) signal output jack
15. RS-232 control port
16. AC power jack
17. Kensington anti-theft lock slot
18. Ceiling mount holes
7
6
18
18
18
8
3
3
3 3
5
4
1
2
9
10 11
12
16
17
13 14 15
