Connection 19
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
• In the connections shown below, some cables may not be included with the
projector (see "Shipping contents" on page 8). They are commercially available
from electronics stores.
• For detailed connection methods, see pages 20-23.
1
2
USB
HDMI
6
1
7
HDMI
USB
HDMI
HDMI
1
3
4
5
3
8
9
To Next Page
