BenQ TH685P - Projector Exterior View; Component Identification

8 Introduction
Projector exterior view
1. Focus ring and Zoom ring
2. Vent (air exhaust)
3. Adjuster feet
4. Projection lens
5. IR remote sensor
6. External control panel
(See Controls and functions on page 9.)
7. Lamp cover
8. Ambient Light Sensor (ALS)
9. Vent (air inlet)
10. Audio input jacks
Audio output jack
11. HDMI 2 input port
12. HDMI 1 input port
13. USB Type A port
14. RS-232 control port
15. AC power jack
16. Kensington anti-theft lock slot
17. Ceiling mount holes
7
6
17
17
17
9
8
3
3
3 3
5
4
1
2
10
11 12
13
15 16
14
