27
4.1 Auto color
FLUKE 54200
Full polychrome
color bar 100_0
1. Press CH▲▼Key To select Auto
Color
And then VOL▲ Key to enter
2. To confirm
Full polychrome
Color bar 100_0 is right.
11. After confirmed,
then enter into
User mode
PC or Pattern
Generator
Preset mode 3. To confirm each adjustment values is
right and then press Power off.
4. after that, press Power On to enter
into User
mode
6. USER MODE
testing
6.1 TV testing
1.the center signal
2. TV Signal
Generator
3. VG-848
4. FLUKE 54200
1. Press Source Key to open OSD.
2. Press CH▲▼Key to choose TV .
3. Press VOL▲ Key to enter to.
2. According to signal source , doing picture
and volume test.
3. Press MENU to open OSD.
4. Press CH▲▼Key to select and press
VOL▲ Key to enter. After that ,doing each
function and confirm whether each
function is right.
5. After finished, choose MENU to exit.
6.2 AV testing
1. DVD PLAYER
2. VG-848
3. FLUKE 54200
1. Press SOURCE Key to choose AV.
2. According to signal source , doing picture
and volume test.
3. Press MENU to open OSD.
4. Press CH▲▼Key to select and press
VOL▲ Key to enter. After that ,doing each
function and confirm whether each
function is right.
5. After finished, choose MENU to exit.
