6.3 YPBPR testing
1. DVD PLAYER
2. VG-848
3. FLUKE 54200
1. Press SOURCE Key to select YPBPR.
2. According to signal source , doing picture
and volume test.
3. Press MENU to open OSD.
4. Press CH▲▼Key to select and press
VOL▲ Key to enter. After that ,doing each
function and confirm whether each
function is right.
5. After finished, choose MENU to exit.
6.4 SCART testing
1. DVD PLAYER
2. FLUKE 54200
1. Press SOURCE Key to select SCART1.
2. According to signal source ,doing picture
and voice test.
3. Press MENU to open OSD.
4. Press CH▲▼Key to select and press
VOL▲ Key to enter ,after that ,doing each
function and confirm whether each
function is right.
5. After finished, choose MENU to exit.
6.5HDMI/DVI
testing
1. DVD PLAYER
2. PC or Pattern
Generator
1. Press SOURCE Key to select HDMI.
2. According to signal source , doing picture
and volume test.
3. Press MENU to open OSD.
4. Press CH▲▼Key to select and press
VOL▲ Key to enter. After that ,doing each
function and confirm whether each
function is right.
5. After finished, choose MENU to exit.
