14
4.1 Auto color
FLUKE 54200
Full polychrome
color bar 100_0
1. Press CH▲▼Key To select Auto
Color
And then VOL▲ Key to enter
2. To confirm
Full polychrome
Color bar 100_0 is right.
5. After confirmed,
then enter into
User mode
PC or Pattern
Generator
Preset mode 1. To confirm each adjustment values is
right and then press Power off.
2. after that, press Power On to enter
into User mode
6. USER MODE
testing
6.1 TV testing
1.the center signal
2. TV Signal
Generator
3. VG-848
4. FLUKE 54200
1. Press Source Key to open OSD.
2. Press CH▲▼Key to choose TV .
3. Press VOL▲ Key to enter to.
4. According to the center signal doing
picture and voice test. .
5. Press MENU to open OSD.
6. Press CH▲▼Key to choose and
press VOL▲ Key to enter ,after
that ,doing each function and confirm
whether each function is right.
7. After finished, choose MENU to exit.
6.2 AV testing
1. DVD PLAYER
2. VG-848
3. FLUKE 54200
1. Press SOURCE Key to choose AV.
2. According to signal source, doing
picture and voice test.
3. Press MENU to open OSD.
4. Press CH▲▼Key to select and press
VOL▲ Key to enter ,after that ,doing
each function and confirm whether
each function is right.
5. After finished, choose MENU to exit.
