- 48 -
5.5.3 Power no work troubleshooting
Check F601,
Q601, OK?
Replace
F601,
Q601
Replace
IC601
Check IC801
OK?
Replace
D851,L851
Replace
IC851
Check I/F BD
Check D851, L851,
OK?
Replace
panel
Check D705
OK?
Backlight did not
shine
Replace
D703
Replace
D705
D703 D704
+5.0V OK?
LED-20V
OK ?
Check D703
OK
OK ?
Check CN701
PIN1 (BL-ON)
is HI?
Check CN701
PIN2 is HI?
