Section Contents Page No
1.0 Compliance Notices
4
1.1 Certificates of Conformity 5
1.2 General product Information 5
1.3 General Requirements 6
1.4 Delivery & Pre-installation Checks 6
1.5 Warranty 7
Special risk areas 7
2.0 Installation
8
2.1 Installation Clearances and Mounting Heights 8
2.2 Heater Mounting 8
2.3 Warm Air Circulation 9
2.4 Air Supply 9
2.5 Flue Installation 13
2.6 Electrical Installation 17
2.7 Gas Installation 18
3.0 Commissioning
19
3.1 Electrical Pre tests 19
3.2 Gas pre tests 19
3.3 Ignition Sequence 20
3.4 Hand Over 21
4.0 Servicing
21
4.1 Servicing Procedure 21
5.0 Fault Diagnosis
23
6.0 Wiring Diagrams
25
7.0 Technical Data
30
7.1 Technical Data Common Information 30
Pre Purge information 32
7.2 Technical Data Heater Specifications 33
8.0 Parts Listing
34
9.0 Dimensions
35
